GXN46I04 Facial recognition server

Excellent performance

lDual slot 3rd Intel Xeon series processors support 270W TDP;

lGPU optimization design supports four dual slot active or passive GPUs, including NVIDIA ® A100

Enriching and expanding

lSupport NVIDIA NVLink ® Network bridge, scalable performance to meet the demands of visual computing workloads;

lUp to twelve 3.5-inch or 2.5-inch hard drive bits for higher storage and high throughput performance;

lOptimized energy-saving heat dissipation design and independent CPU and GPU air ducts.

Easy management

lRemote management, where real-time monitoring of the system and real-time operations including power on and off can be carried out remotely;

Ready to use out of the box

lcan pre install Ubuntu operating system, etc

lDelivered in container form, ready to use immediately after opening the box, improving work efficiency.

Central Processing Unit

3rd Gen Intel® Xeon® Scalable processors, Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s

Memory capacity

Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 6TB Intel® Optane™ Persistent Memory 200 Series, in 16 DIMM slots;
Up to 6TB Intel® Optane™ DC Persistent Memory in memory mode.

Chipset

Intel® C621A

storage

M.2 Interface: 2 PCIe 4.0 x4, RAID 0 & 1
M.2 Form Factor: 2242/2260/2280/22110
M.2 Key: M-Key
Intel® C621A controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10

LAN

IPMI ASPEED AST2600 BMC
Dual LAN with Intel® X550 10GBase-T Ethernet Controller

Input/Output

2 USB 2.0 port(s) (2 via header)
7 USB 3.1 Gen1 port(s) (2 via header; 4 rear type A; 1 rear type C)
1 VGA D-Sub Connector port(s)
2 COM Port(s) (1 header; 1 rear)
2 SuperDOM (Disk on Module) port with build power
1 TPM Header

Appearance and morphology

4U Rackmountable with Rail kit

height

87mm

width

447mm

depth

666mm

Disk slot

3.5" Hot-swap：8
Slim ODD：1
Internal 2.5"：2
M.2 Interface: 2 PCIe 4.0 x4, RAID 0 & 1

PCI-Express

1 PCIe 4.0 x8,
6 PCIe 4.0 x16

source

2000W (1+1) Redundant power supplies

Environmental specifications

Operating Temperature Range
10°C - 35°C (50°F - 95°F)
Non-Operating Temperature Range
-40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range
8% - 90% (non-condensing)
Non Operating Relative Humidity Range
5% - 95% (non-condensing)

OS

Windows Server 2019 64bit
RHEL 8.3 64bit
Fedora 32 64bit
Fedora 33 64bit
SLES 15 SP3 64bit
Ubuntu 20.04.1 LTS 64bit DT
VMWare ESXi 7.0 GA x64
Oracle Linux 8.2
CentOS 8.2 64bit
